EZ DOCK

System

  • EZ Dock is a Single-mould polyethylene dock. Also known as ‘Integrated Flotation’.

  • Hydro-static Surface Tension. Air is trapped in the underside cavities to create suction below the surface for stability.

  • EZ Dock | 62.5 lbs/sqft | 305.2 kg/sqm

  • EZ Dock is a self-contained unit that uses only trapped air inside the dock. It also has underside cavities to trap air between the dock and the water surface.

  • Dock Sections
    Made of roto-moulded LLDPE (Linear Low-Density Polyethylene)

    Connectors
    Recycled Vulcanized Rubber (made from heavy duty truck tires)

    Nut Bolts & Connecting Rods
    Nylon/Composite

  • Rating: UV-16 Stabilizer

    EZ Docks are tested for 16,000 hours.
    Tested Durability: 20-30 year lifespan, against sun-related cracking, fading or degradation.

    This is double the industry standard degradation testing.

  • EZ Dock: 13.1 MPa (1,900 psi)

Wave Armor

System

  • Wave Armor is a 2-piece Single-mould polyethylene dock. Its flotation is sealed like a single-mould, and has a fitted deck portion.

  • Hydro-static Surface Tension. Air is trapped in the underside cavities to create suction below the surface for stability.

  • Wave Armor | 50.0 lbs/sqft | 244.1 kg/sqm

  • Air Pockets
    and
    EPS (Expanded Polystyrene)

  • Dock Sections
    Made of roto-moulded HDPE (High-Density Polyethylene) filled with EPS foam

    Connectors
    Roto-moulded HDPE (High-Density Polyethylene) H-Beams

    Nut Bolts & Connecting Rods
    Stainless Steel and Galvanized Steel

  • Wave Armor UV

    Rating: UV-8 Stabilizer

    Tested Durability: 20+ year lifespan against sun-related cracking, fading, or degradation.

Poly-Dock

System

  • PolyDock is a Single-mould polyethylene dock. Also known as ‘Integrated Flotation’.

  • Hydro-static Surface Tension. Air is trapped in the underside air cavities to create suction below the surface for stability.

  • PolyDock | 65.0 lbs/sqft | 317.4 kg/sqm

  • PolyDock is a self-contained unit that uses only trapped air inside the dock. It also has underside cavities to trap air between the dock and the water surface.

  • Dock Sections
    Made of roto-moulded HDPE (High-Density Polyethylene).

    Connectors
    UV-stabilized polyethylene with internal composite rods.

    Nut Bolts & Connecting Hardware
    Stainless steel fasteners and composite rods.

  • Rating: UV-8 Inhibitor rating

CanDock

System

  • CanDock is a Cube Style Dock design type. Single piece construction.

  • Candock’s standardized units utilize the displacement buoyancy principle.

  • CanDock | 60.0 lbs/sqft | 292.8 kg/sqm

  • CanDock is a self-contained unit that uses only trapped air inside the dock.

  • Dock Sections
    Made of roto-moulded HDPE (High-Density Polyethylene)

    Connectors
    CanDock connectors (pins and nuts) are all HDPE (high-density polyethylene resin), same as the dock sections.

  • Rating: Undisclosed

AccuDock

System

  • AccuDock is a multi-piece hybrid dock system. It is a Polyethylene dock, but it uses an aluminum frame and HDPE-encapsulated foam floats (flat sheets over EPS core).

  • AccuDock units utilize the displacement buoyancy principle.

  • AccuDock | 62.0 lbs/sqft | 302.8 kg/sqm

  • AccuDock uses foam filled compartments encased in HDPE.

  • Dock Sections
    HDPE sheets encapsulating EPS foam core.

    Connectors
    Marine-grade aluminum (S/H/T-style) with stainless steel bolts.

  • Rating: UV-8 Inhibitors

SnapDock

System

  • SnapDock is a Single-mould Integrated Flotation Dock Type.

  • SnapDock
    Uses Hydro-static Surface Tension. Air is trapped in the underside air cavities to create suction below the surface for stability.

  • Snapdock | 62.0 lbs/sqft | 302.8 kg/sqm

  • SnapDock is a sealed dock section with trapped air as its flotation material.

  • Dock Sections
    Rotationally moulded linear low-density polyethylene (LLDPE).

    Connectors
    Injection moulded LLDPE couplers with 5/8" stainless steel bolts, washers, and locknuts.

  • Rating: Undisclosed

Connect-a-Dock

System

  • Connect-a-dock is a Single-mould Integrated Flotation Dock Type.

  • Connect-a-dock
    Uses Hydro-static Surface Tension. Air is trapped in the underside air cavities to create suction below the surface for stability.

  • Connect-A-Dock | 63.0 lbs/sqft | 308.6 kg/sqm

  • Connect-a-Dock sections utilize trapped air construction to float.

  • Dock Sections
    Rotationally moulded high density polyethylene (HDPE).

    Connectors
    Also made of HDPE

  • Rating: UV-8

Floating

Dock

Systems

Takeaways

Floating Dock technology has come a long way, and it continues to make strides to address the toughest on-water challenges.

It’s no longer a question of can a floating dock do this..

.. and more of a, which one is best!
